ML Plum Coupling

Rokee^® is a ML Plum Coupling Supplier from China, customized ml plum coupling according to the drawings which provided by the customer, selling chinese national standard ml plum coupling, support export, due to excellent quality, complete technical services and superior cost performance, Rokee^® industrial coupling have been serving more than 60 countries and regions in the world, effectively operating in many corners of the world.

The plum coupling is composed of two semi-couplings with convex claws and a plum-shaped flexible non-metallic element whose hardness can be adjusted. By embedding the plum-shaped flexible element into the two semi-couplings to realize the connection, it has the characteristics of compensating the relative displacement of the two axes, reducing vibration and buffering, simple structure and easy maintenance without lubrication.

Flexible plum blossom coupling is made up of semi-shaft coupling with the same protruding claw and flexible component.utilizing the plum blossom elastic component put between the protruding claw and two half shaft coupling.in order to realize the connection of two semiaxis devices.

Jaw coupling has compensating by two axle to be relative skew,reducing shaking buffering.smaller diameter simple structure.without lubricating.bearing large capacity,and convenient repair But the semi-shaft coupling needs to move along the axial while changing the elastic component.

Claw coupling is suitable for two with axis,start frequent,positive and negative change,low-speed and medium speed.medium and small powerrotate axle department,requiring working dependability high working position;it is not suitable for the heavily loaded and restricted axial in size.Two axis put in the difficult position after exchange of flexible component.

• LMPK Plum-shaped Flexible Coupling

  LMPK Plum-shaped Flexible Coupling adopts split brake disc design, suitable for situations where braking is required and eliminating the need of axially moving the semi-coupling when replacing the elastomer.
• LMZ-II Plum-shaped Flexible Coupling

  LMZ-II Plum-shaped Flexible Coupling adopts integral brake wheel design, suitable for situations where braking is required.
• LMZ-I Plum-shaped Flexible Coupling

  LMZ-I Plum-shaped Flexible Coupling adopts split brake wheel design, suitable for situations where braking is required.
• LMS Plum-shaped Flexible Coupling

  LMS Plum-shaped Flexible Coupling adopts double transition flange connection, which eliminates the need of axially moving the semi-coupling when replacing the elastomer.
• LMD Plum-shaped Flexible Coupling

  LMD Plum-shaped Flexible Coupling is added with transition connection, which eliminates the need of axially moving the semi-coupling when replacing the elastomer.
• LM Plum-shaped Flexible Coupling

  LM Plum-shaped Flexible Coupling is the basic form of this series of couplings.
